Description
The HP Latex 830 Printer is a 64-inch wide format HP Latex production printer built for commercial sign shops, print providers, wrap installers, and graphics businesses that need fast, reliable roll-to-roll output. Designed for high-volume CMYK latex printing, the Latex 830 helps shops produce banners, displays, vehicle graphics, wall décor, window graphics, posters, textiles, stickers, murals, and exterior signage with consistent quality and efficient production speed.
With water-based HP Latex Inks, the HP Latex 830 produces odorless prints that come out dry and ready for finishing. This helps reduce production delays by allowing prints to move directly to lamination, trimming, cutting, or installation. The Latex 830 is a strong fit for shops that need durable indoor and outdoor graphics without waiting on extended drying times.
The HP Latex 830 is designed for high-throughput production with 3-liter ink cartridges, print speeds up to 388 ft²/hr in draft mode, roll media support up to 64 inches wide, and automated media handling tools including roll feed, take-up reel, media saver, wiper roller, and automatic horizontal cutter. With consistent HP Latex print quality, automated maintenance, and intuitive operation, the Latex 830 helps busy shops keep production moving across a wide range of flexible media applications.
Specifications
- 64-inch HP Latex production printer for signage, graphics, décor, and display production
- Water-based HP Latex Inks produce odorless prints that are dry and ready for finishing
- 3-liter ink cartridges support higher-volume production workflows
- Print speeds up to 388 ft²/hr in draft mode
- Print resolution up to 1200 x 1200 dpi
- Supports roll media up to 64 in. wide and up to 121 lb.
- Roll feed, take-up reel, wiper roller, media saver, and automatic horizontal cutter
- Automated maintenance and calibration help reduce downtime and simplify operation
Popular Applications
- Banners and Posters
- Vehicle Graphics and Wraps
- Exterior Signage
- Window Graphics
- Wall Décor and Interior Graphics
- POP/POS Displays
- Exhibition and Event Graphics
- Light Box Graphics
- Textiles and Soft Signage
- Stickers and Decals
| MODEL | HP Latex 830 Printer |
| PRINT TECHNOLOGY | HP Latex Printing Technologies |
| INK TYPE | Water-based HP Latex Inks |
| INK CONFIGURATION | Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Optimizer, and Overcoat |
| INK CARTRIDGE SIZE | 3 L per cartridge |
| INK CARTRIDGES | 8 cartridges: Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Optimizer, and Overcoat |
| PRINTHEADS | 8 printheads: 7 HP Latex Printheads and 1 HP Latex Optimizer Printhead |
| MAX MEDIA WIDTH | 64 in. |
| PRINT RESOLUTION | Up to 1200 x 1200 dpi |
| PRINT SPEED | 388 ft²/hr Draft, 269 ft²/hr Speed, 215 ft²/hr Standard, 183 ft²/hr Quality, 118 ft²/hr High Quality |
| MEDIA HANDLING | Roll feed, take-up reel, wiper roller, media saver, and automatic horizontal cutter for vinyl, banner, canvas, paper-based media, and film |
| ROLL SIZE | 16.5 to 64-in rolls, with full support for 23 to 64-in rolls |
| MAX ROLL WEIGHT | 121 lb. |
| MAX ROLL DIAMETER | 9.8 in. |
| MEDIA THICKNESS | Up to 19.7 mil |
| MEDIA TYPES | Banners, self-adhesive vinyls, films, fabrics, papers, wallcoverings, canvas, synthetics, mesh, and textiles |
| CONNECTIVITY | Gigabit Ethernet 1000Base-T |
| POWER REQUIREMENTS | 200-240 V, two wires and PE, 50/60 Hz, two power cords, 16 A max per power cord |
| POWER CONSUMPTION | 1.5-2.5 kW printing, 5 kW peak, 95 W ready, less than 19 W sleep, less than 0.25 W off |
| ENVIRONMENTAL CERTIFICATIONS | ENERGY STAR®, UL ECOLOGO®, UL GREENGUARD Gold, EPEAT, RoHS, REACH, OSHA, CE, AgBB, and French VOC A+ |
| OPERATING TEMPERATURE | 59° to 86° F |
| OPERATING HUMIDITY | 20 to 80% RH, non-condensing |
| ACOUSTICS | 60 dB(A) printing, 38 dB(A) idle, less than 20 dB(A) sleep |
| PRINTER DIMENSIONS | 101.7 in. W x 34.1 in. D x 55.2 in. H |
| SHIPPING DIMENSIONS | 108.4 in. W x 43.3 in. D x 65.6 in. H |
| OPERATING AREA | 110 in. x 82.7 in. |
| PRINTER WEIGHT | 644 lb. |
| SHIPPING WEIGHT | 948 lb. |
| WARRANTY | One-year limited hardware warranty |
| INCLUDED ITEMS | HP Latex 830 Printer, printheads, maintenance cartridge with ink collection unit, additional ink collection unit, condensation collector kit, power cords, beacon accessory, manual purge syringe kit, user maintenance kit, edge holders, 2-in spindle adaptor, lubrication felts kit, quick reference guide, documentation software, spanner size 17, and screwdriver T-25 |
Downloads
HP Latex 830 Printer Data Sheet
