Description
What’s the best way to make your production even better? Shorten film loading time? Make fewer film changes? Increase throughput speed? The 563TH-3 does all that and more. The perfect laminator for maximum productivity.
Specifications
- Maximum productivity with 50% faster throughput.
- Fast Roll changes with front/rear swing-out shafts.
- Easy loading with 3" aluminum quick-grip shafts.
- Rugged design features metal alloy heaters.
- Versatile roll-to-roll capability
Popular Applications
- Signs
- Banners
- Trade show displays
- Point-of-purchase
- Dry-erase boards
- Floor graphics
- Graphic mounting
- Photo mounting
- Window graphics
- Vehicle graphics
| LAMINATING WIDTH | 63" |
| ROLLER DIAMETER | 4.5" |
| ROLLER GAP | 1" |
| REAR REWIND | Optional |
| MAX TEMPERATURE | 122°F |
| MAXIMUM SPEED (feet/minute) | 0-20 ft/min |
| PRESSURE/GAP ADJUSTMENT | Hand Wheel |
| HEATING METHOD | Metal Alloy Heater |
| MAXIMUM ROLL DIAMETER | 8" OD (top); 16" OD (bottom) |
| SUPPLY SHAFTS | 2 Swing-out |
| TENSION ADJUSTMENT | Single knob |
| POWER SUPPLY | 110v 12A |
| POWER CONSUMPTION | 1320W |
| FOOT PEDAL | Included |
| STAND WITH CASTERS | Included |
| NET WEIGHT WITH STAND | 502 lbs. |
| DIMENSIONS | 82" x 28.5" x 50" |
| MACHINE SHIPPING | 530 lbs. 89.4" x 33.1" x 29.2" |
| STAND SHIPPING | 143 lbs. 75" x 33" x 5.8" |
Downloads
Gfp 563TH-3 Top Heat Laminator Specification Sheet
