Description
For finishing professionals who need versatility, quality, and economy in one machine, the Gfp 865DH-3 delivers. Turn out thermal encapsulation with low melt films (1.5-10mil), PSA lamination, and mounting jobs quickly and easily
Specifications
- Ultimate flexibility with dual heat for thermal and cold applications.
- Professional features that produce professional results.
- Fast roll changes with front and rear swing-out shafts.
- Easy loading with 3" quick-grip swing-out shafts.
- Rugged industrial design for years of maintenance-free service.
Popular Applications
- Signs
- Posters
- POP displays
- Trade show displays
- Dry-erase boards
- Graphic mounting
- Photo mounting
- Floor graphics
- Window graphics
- Vehicle graphics
| LAMINATING WIDTH | 65" |
| ROLLER DIAMETER | 5" |
| ROLLER GAP | 1" |
| MAIN ROLLERS | Silicone |
| SUPPLY ROLL DIAMETER (MAX) | 16" bottom, 8" top |
| FILM SHAFTS | 3" aluminum quick-grip |
| REAR REWIND | Optional |
| MAXIMUM TEMPERATURE | 266°F |
| HEAT METHOD | Quartz heater |
| FILM THICKNESS | 1.5 - 10mil |
| LAMINATING SPEED (FEET/MINUTE) | 0-13 ft/min |
| DRIVE MOTOR | DC geared motor |
| PRESSURE ADJUSTMENT | Dual hand wheels |
| ROLLER HEATING | Top and bottom |
| POWER SUPPLY | 240v 60HZ single phase 24A |
| POWER CONSUMPTION | MAXIMUM 5760W |
| NET WEIGHT WITH STAND | 767 lbs. |
| DIMENSIONS | 87" x 34" x 49" |
| MACHINE SHIPPING | 893 lbs. 90" x 38" x 33" |
| STAND SHIPPING | 134 lbs. 79" x 33" x 15" |
Downloads
Gfp 865DH-3 Dual Heat Laminator Specification Sheet
